Alubox B 400/500 RAL 9005 matte black

Aluminum box made of sturdy aluminum tread plate – robust, lockable & individually configurable

This high-quality cargo box made of 1.5 mm thick aluminum tread plate is the ideal solution for workshops, vans, trailers, or off-road vehicles. It impresses with maximum stability, well-thought-out details, and reliable splash protection (IP54).

Whether for side or top mounting – the opening can be chosen to face upwards or backwards, providing comfortable access to your equipment.

✅ Technical Details & Equipment

• Material: 1.5 mm aluminum tread plate
• Dimensions: Width 1000–2000 mm / Height 400 mm / Depth 500 mm
• Surface: raw or powder-coated in RAL colors
• Splash protection: IP54 due to circumferential flange & rubber seal
• Stability: internal edge protection for corner reinforcement
• Opening aid: 2 gas struts for automatic opening & keeping open
• Locking: 2 integrated recessed locks with seal
• Locking system: 2 keys, keyed alike
• Hinges: V2A stainless steel – rustproof & durable
• Mounting: grab handle for top mounting


🔒 Secure & weather-protected

The circumferential flange combined with a high-quality rubber seal reliably protects the contents from splash water and dust. Ideal for use on vehicles or trailers.

🛠 Sturdily constructed for daily use

The solid tread plate as well as the internal corner reinforcement ensure high dimensional stability – even under heavy stress in commercial use or off-road areas.

🎨 Custom manufacturing possible

Is your desired size not listed? Do you need a special RAL color?

No problem – we also manufacture the cargo boxes individually to measure.
Simply write to us via the contact form – we are happy to advise you.
