ARB Brushless Air Compressor
ARB Brushless Air Compressor
Couldn't load pickup availability
The ARB Brushless Air Compressor delivers 50% more air volume for faster inflation, with intelligent cooling and easy installation.
Compatible with
- Volkswagen - Crafter 1st generation (2006 - 2017)
- Volkswagen - Crafter 2nd generation (2017+)
- Hymer - Free S Campus
- Dethleffs - Globetrail Performance
- Volkswagen - Grand California 600/680
- Hymer - Grand Canyon S
- Hymer - Grand Canyon S Crossover
- Westfalia - James Cook
- Yucon - K-Peak
- Hymer - ML-T Crossover
- Mercedes Benz - Sprinter W906 (2006 - 2018)
- Mercedes Benz - Sprinter W907 (2018+)
- Mercedes Benz - Sprinter W910 (2018+)
- Westfalia - Sven Hedin
- MAN - TGE (2017+)
- Yucon - V-City
- Hymer - Venture S
Benefits of the ARB Brushless Air Compressor for your campervan
The ARB Brushless Air Compressor is the latest innovation in air compressor technology, specifically developed for demanding camper and off-road users. With 50% more air volume than previous models, you can inflate tires faster and get back on the road sooner. Brushless motors with active fans ensure durable and reliable performance, while intelligent electronics provide real-time diagnostics and protection against voltage spikes and overload. Compatible with ARB Air Lockers as well as various ARB inflation kits and hoses, facilitating easy integration. The quick-release mounting system allows for simple installation and removal. This model is compatible with the ARB Digital Tire Inflator and the ARB Tire Inflation Hose.
Installation requirements for the ARB Brushless Air Compressor
Please note: This compressor is not directly compatible with our standard Twin Compressor mounting kit. However, the mounting plate can be adapted by drilling new holes to accommodate the compressor's mounting points.
The compressor operates at 12V and is designed for installation in campervans and 4x4 vehicles. The brushless motor eliminates the need for external relays, thereby simplifying installation. The Smart Start system ensures staggered activation of the two motors, reducing power spikes during startup – ideal for vehicles with smaller charging systems. Preferably install the compressor in a well-ventilated, dry location.
Specifications for the ARB Brushless Air Compressor
- Voltage: 12V
- Width: 33.8 cm
- Height: 17 cm
- Length: 36.8 cm
- Weight: 7.2 kg
- Maximum current draw: 90A
- IP rating: IP67 (waterproof)
- Duty cycle: 100%
- Air flow at 0 PSI: 260.1 L/min
- Air flow at 2 bar (29 PSI): 175.6 L/min
- Design: Brushless, onboard
- Prop 65: No
- Warranty: 3 years
Product notice
Regulations for inflation kits and air compressor systems vary by country. It is your responsibility to check the applicable regulations in your country. Vanstudio assumes no liability or responsibility for legal requirements or potential issues with this product.
